Rocky Mountain Solo Carbon 90 BC Edition
$5,999.00
Details
Designed to make every ride an adventure, the Solo is the perfect tool to escape, log some miles, and make multi-day rides a blast.
| xs | sm | md | lg | xl | |
|---|---|---|---|---|---|
| Top Tube Horizontal (mm) | 521 | 542 | 562.2 | 582 | 607 |
| Head Tube Angle (deg) | 69.2 | 69.7 | 70.2 | 70.7 | 70.7 |
| Head Tube Length (mm) | 100 | 130 | 150 | 185 | 210 |
| Seat Tube Angle (deg) | 74.2 | 73.7 | 73.2 | 72.8 | 72.3 |
| Seat Tube Length (mm) | 414 | 452 | 490 | 528 | 605 |
| Rear Centre (mm) | 425 | 425 | 425 | 425 | 425 |
| Bottom Bracket Drop (mm) | 72.5 | 71.6 | 69.6 | 69.6 | 69.6 |
| Reach (mm) | 369 | 376 | 384.5 | 388 | 400 |
| Stack (mm) | 543 | 572 | 590 | 625.5 | 650 |
| Standover Height (mm) | 760 | 791 | 820 | 855 | 881 |
| Wheelbase (mm) | 1025 | 1038 | 1049 | 1060 | 1080 |
Specs
| Frame | Rocky Mountain Smoothwall Carbon | BB386 | Zero Stack Tapered Headtube | Fully Guided Internal Cable Routing | Dropper Post Compatible | 142mm Dropouts | Sram UDH Compatible |
|---|---|
| Fork | RockShox Rudy Ultimate XPLR 30mm | 51mm Offset |
| Rims | Rocky Mountain 27GR Carbon | SL GR Design |
| Hubs | Front Hub: Zipp ZR1 12mm/Rear Hub: Zipp ZR1 142mm |
| Spokes | Pillar PSR 2.2/1.5/2.0 |
| Tires | WTB Resolute TCS Light Fast Rolling Dual DNA SG2 700 x 50c | WTB Resolute TCS Light Fast Rolling Dual DNA SG2 700 x 50c |
| Bottom Bracket | Sram BB386 DUB Wide |
| Crankset | Sram Force 1 Wide Carbon | 42T | DUB Spindle | Crankarm Length: XS-SM = 170mm | MD = 172.5mm | LG-XL = 175mm |
| Shifters | Sram Force AXS |
| Rear Derailleur | Sram X0 Eagle Transmission Wireless |
| Cassette/Freewheel | Sram XX Eagle SL Transmission 10-52T |
| Chain | Sram XX Transmission |
| Brakes | Sram Force |
| Handlebars | Easton EC70 AX | 80mm Reach | 120mm Drop | Flare 16° | Width: 420mm XS | 440mm SM-MD | 460mm LG-XL |
| Tape/Grips | Rocky Mountain Gel Bar Tape |
| Stem | Rocky Mountain 31.8 XC | 5° Rise | XS = 60mm | SM = 70mm | MD = 80mm |LG = 90mm | XL = 100mm |
| Headset | FSA Orbit NO.57E | Sealed 36°x45° Bearings | 30.2mm x 41mm x 6.5mm Upper | 40mm x 51.8mm x 8.0mm Lower | 1.5" Crown Race |
| Seatpost | Easton EC70 27.2mm |
| Saddle | WTB Silverado Race 142 | Cromoly Rails |
* Subject to change without notice.
Part Numbers
| Option | UPC | MPN |
|---|---|---|
| Seven Nation Army/Black Dog / X-Small / 700c | 770416007084 | B0453XS1 |
| Seven Nation Army/Black Dog / Small / 700c | 770416007046 | B0453SM1 |
| Seven Nation Army/Black Dog / Medium / 700c | 770416007022 | B0453MD1 |
| Seven Nation Army/Black Dog / Large / 700c | 770416007008 | B0453LG1 |
| Seven Nation Army/Black Dog / X-Large / 700c | 770416007060 | B0453XL1 |
